Description
| COMPLLETE VEHICLE SPECIFICATION | |||
| （mm） | Length
|
4500
|
|
| （mm） | Width | 1680 | |
| (mm） | Height | 2000
|
|
| （mm） | Wheelbase | 3050 | |
| （mm） | Front/Rear overhang | 570/880 | |
| Angle of approach/Departure | 21/26 | ||
| （Kg） | Curb weight | 1530 | |
| （Kg）
|
Maximum total mass | 2550 | |
| Maximum passengers | 8+2+1 | ||
| （Km/h） | Maximum speed | 100 | |
| Maximum gradability | ≥20% | ||
| （mm）
|
Minimum ground clearance |
≥185
|
|
| （m）
|
Minimum turning radius | ≤11 | |
| Cruise mileage(km)(fully loaded) | ≥180 | ||
| CHASSIS SPECIFICATION | ||||
| Items | Specification | Remarks | ||
| Motor | 30/60Kw | 30/60Kw，PMSM | ||
| Front axle | Disc brake | |||
| Rear axle
|
Drum brake | |||
| Suspension
|
Front independent suspension, rear leaf spring suspension | |||
| Tyre | 195R14LT | 195R14LT | ||
| Steel rim | Yes | |||
| Parking brake | Hand brake | |||
| Steering system | Electronic assistance | |||
| Steering wheel | Chinese brand | |||
| ABS | ABS | Yes | ||
| Tool kit | Yes | |||
| BODY SPECIFICATION | |
| Drive mode
|
RHD |
| Sun visor | 2 |
| chair | Driver manual four-way adjustment, fabric seat fabric |
| Exterior rearview mirror | Manual, adjustable |
| Interior rearview mirror | Yes |
| car window | Power windows |
| car door | Left and right front doors + Manual side sliding door |
| Front windshield | Double laminated glass |
| Driver’s door and window | Driver’s door and passenger’s door electric window, white toughened glass |
| Cargo window glass | White tempered glass |
| Paint | Solid color paint |
| Miscellaneous
|
The last row of seats can be folded
Roof luggage rack
|
| ELECTRICAL SPECIFICATION | ||||
| Power Battery pack | 38.7Kwh | 38.7Kwh | 41.93 | |
| AC | YES
|
|||
| 12V/Battery | 12V | 12V
|
||
| Wiper | YES | |||
| dipped headlight | YES | |||
| high beam | YES | |||
| Rear fog lamp | YES | |||
| Instruments | YES | |||
| USB | 1 | |||
| Central locking | YES | |||
| Audiovisual system | radio | |||
| Charging receptacle | Chinese Standard | |||
| Miscellaneous
|
Eco | Eco
Reversing image |
||
| QUOTATION | · | |||
| Warranty
|
2 years or 120,000km which comes first | |||
| HV parts(Battery, Motor, Controller,etc.) 5 years or 20 km which comes first
|
||||
